MULTIPLE FRAME OPTIONS
Besides offering the BIG.NINE in a full carbon version, we also have BIG.NINE LITE and BIG.NINE/ SEVEN TFS aluminium frames in our range. While the LITE features the same race-proven geometry as the carbon models, the TFS bikes offer a more relaxed geometry, through a shorter top tube and a higher head tube, resulting in a more upright riding position and enhanced trail visibility. The TFS frames feature internal cable routing (except the BIG.NINE/BIG.SEVEN 15), smooth welding, tapered head tube, inboard disc mounts, and mounts for fenders, rear rack and kickstand.
THIS IS WHAT WE DO
Our classic hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we were able to gain in 48 years of bike production and manufacturing. The BIG.NINE and BIG.SEVEN range symbolises the symbiosis between modern frame technology, attention to detail and craftsmanship 'Made in Taiwan'.
Availability Everything found in the catalog is available in our stores and warehouses | |||||
---|---|---|---|---|---|
Color: | Frame size: | Price: | Location: | Barcode: | |
Blue / Yellow | 14.5" / S | 679.00 EUR | K28 |
6110887232006
|
Add to cart |
Blue / Yellow | 17" / M | 679.00 EUR | K28 V |
6110887243002
|
Add to cart |
Specification | |
---|---|
Stem | MERIDA CC Aluminium 31.8mm diameter 6° stem angle 70 mm-S, 80 mm-M, 90 mm-L, 100 mm-XL, 110 mm-XXL |
Permitted max. weight | 135 kg |
Suspension | Front suspension |
Cassette | Sunrace CSM668 11-32 teeth 8 speed |
Tyres | MERIDA K1080 29x2.2" wire |
Spokes | Black steel |
Shift levers | Shimano ST-EF505 |
Seatpost | MERIDA CC Aluminium 30.9mm diameter 15mm setback |
Seat clamp | MERIDA COMP QR |
Saddle | MERIDA Sport comfort |
Rims | MERIDA CC 17mm inner width Aluminium |
Pedals | VP VPE-891 |
Rear hub | Shimano TX505 100x9mm width front hub 32 spoke holes Centerlock |
Front hub | Shimano TX505 100x9mm width front hub 32 spoke holes Centerlock |
Headset | MERIDA M2345 |
Brakes | Hydraulic disc brakes |
Handlebars | MERIDA CC Aluminium 690mm width 15mm rise |
Grips | MERIDA EC |
Rear derailleurs | Shimano RD-M360 |
Front derailleurs | Shimano FD-TY700 |
Crankset | Shimano TY301 42-34-24 teeth 170 mm-S, 175 mm-M/XXL |
Chain | Sunrace M84 |
Rear brakes | Shimano ST-EF505 BR-MT200 brake caliper ROTORS Shimano RT10 160 mm rotor |
Front brakes | Shimano ST-EF505 BR-MT200 brake caliper Shimano RT10 160 mm rotor |
Bottom bracket | FSA TH-7420ST-W, Cartridge Bearing |
Fork | Suntour XCT30 HLO Coil 100mm suspension travel lockout 29x2.25" max. wheelsize |
Gears | 8 x 3 |
Frame | BIG.NINE TFS III Aluminum 29x2.25" max. wheelsize 135x9mm axle standard BSA bottom bracket standard |
Wheel size | 29 " |
Frame material | Aluminium |
Weight | 14.48 kg |
Catalog numbers | 6110887232, 6110887243 |
